PaleoPal

The Philosophy Behind PaleoPal

PaleoPal is an AI-powered assistant designed to accelerate paleoclimate research by combining retrieval-augmented generation (RAG), specialized AI agents, and a comprehensive vector knowledge base derived from notebooks, research papers, and ontologies.

Core Principles

• Domain-Specific Intelligence: PaleoPal understands the unique challenges of paleoclimate research, from SPARQL queries for LinkedEarth datasets to complex time series analysis workflows.
• Multi-Agent Architecture: Specialized agents handle different aspects of research:
  • SPARQL Agent: Generates and refines queries for paleoclimate databases
  • Code Agent: Writes Python code for data analysis and visualization
  • Workflow Agent: Plans multi-step research workflows
• Knowledge-Driven: Built on a vector knowledge base that includes:
  • Notebook snippets and workflows
  • Research paper methods
  • API documentation
  • Ontology entities and relationships
  • SPARQL query templates
• Transparency and Collaboration: Real-time progress visualization, clarification dialogues, and context-aware responses ensure researchers understand and control the AI's reasoning process.

Why PaleoPal?

Paleoclimate research involves complex, multi-step workflows that require deep domain knowledge. Traditional AI assistants lack the specialized understanding needed for tasks like:

• Querying LinkedEarth GraphDB with proper SPARQL syntax
• Understanding paleoclimate data structures and ontologies
• Generating code that follows established analysis patterns
• Planning workflows that integrate multiple data sources and methods

PaleoPal bridges this gap by combining general-purpose AI capabilities with domain-specific knowledge retrieval, making it a true research partner rather than just a code generator.

Installation Instructions

Quick Start with Docker (Recommended)

The easiest way to get started with PaleoPal is using Docker Compose:

# Clone the repository
git clone https://github.com/yourusername/paleopal.git
cd paleopal

# Create environment file
cp backend/env.example backend/.env

# Edit backend/.env with your API keys:
# OPENAI_API_KEY=your_key_here
# ANTHROPIC_API_KEY=your_key_here
# GOOGLE_API_KEY=your_key_here
# XAI_API_KEY=your_key_here

# Start all services
docker compose up -d

# Access the application
# Frontend: http://localhost:3000
# Backend API: http://localhost:8000
# Qdrant Dashboard: http://localhost:6333/dashboard

Local Development Setup

Prerequisites

• Python 3.11+
• Node.js 18+ and npm
• Docker (for Qdrant vector database)

Backend Setup

# Create virtual environment
cd backend
python -m venv .venv
source .venv/bin/activate  # On Windows: .venv\Scripts\activate

# Install dependencies
pip install -r requirements.txt

# Start Qdrant (Docker)
docker run -p 6333:6333 -p 6334:6334 \
  -v qdrant-data:/qdrant/storage \
  --name paleopal-qdrant qdrant/qdrant:v1.7.0

# Configure environment variables
cp env.example .env
# Edit .env with your API keys

# Launch API server
uvicorn main:app --reload

Frontend Setup

# Install dependencies
cd frontend
npm install

# Start development server
npm start
# Frontend will be available at http://localhost:3000

Populating the Knowledge Base

To enable semantic search, you need to populate Qdrant with embeddings:

# Set environment variables
export QDRANT_HOST=localhost
export QDRANT_PORT=6333

# Run the indexing script
cd backend/libraries
bash index_everything.sh

# This indexes:
# - SPARQL queries
# - Ontology entities
# - Notebook snippets and workflows
# - ReadTheDocs documentation
# - Literature methods

VS Code Extension

PaleoPal includes a VS Code extension for integrated research workflows:

1. Open VS Code → Extensions view
2. Click "..." menu → Install from VSIX
3. Select vscode-extension/paleopal-vscode-extension-0.1.0.vsix
4. Configure settings:
   • paleopal.backendUrl: http://localhost:8000/api
   • paleopal.defaultProvider: openai|anthropic|google|ollama|grok

System Requirements

• RAM: Minimum 4GB, recommended 8GB+
• Disk Space: 10GB+ for Docker volumes and dependencies
• API Keys: At least one LLM provider API key (OpenAI, Anthropic, Google, or xAI)

Frequently Asked Questions

cd backend/libraries
python notebook_library/index_notebooks.py --keep-invalid --no-synth-imports notebook_library/my_notebooks
